Shark Platform
• Thin Client with 15 inch or 21.5 inch display
• Rugged design: IP66, shock, vibration and seawater- proof, temp range - 40 °C to +65 °C
• Compact, lightweight HMI design with 15 inch display,
ET < 25 kg / 55 lbs, MT < 18 kg / 40 lbs
• Optional sunlight- readable 15" SR display 1200 cd/ m²
• Sunlight- readable 21.5" SR display as standard with 1000 cd/ m²
• Optional integrated RFID reader for 21.5 inch display
Manta Platform
• Thin Clients as panel- mount device (PM) or Operator Station (OS)
• Panel- mount device (PM) can be installed in hazardous areas without additional enclosure
• Optional resistive glass or foil touch screen
• Display of the 19" (1280 x 1024) resolution true to 5:4 format for the 22" device
• Practical accessories available to extend functionality for the Operator Station (OS)
• Operator Station (OS) versatile due to many different types of enclosures
• Operator Station (OS) mounting versions include wall mounting, pedestal mounting or
mounting on or hanging from elbow
Eagle Platform
• Thin Clients as panel- mount device (PM) or Operator Station (OS)
• Panel- mount device (PM) can be installed in hazardous areas without additional enclosure
• Thin clients with resistive foil touch screen as a standard.
• Practical accessories available to extend functionality for the Operator Station (OS)
• Operator Station (OS) optionally available with enclosure according to GMP requirements,
hygiene- compliant design
• Operator Station (OS) mounting versions include wall mounting, pedestal mounting or
mounting on or hanging from elbow
